Please send RFQ , we will respond immediately.
| Part Number | Q8P3CZZRYG24E | Q8R3CZZRYG24E | Q8P1CZZRYG24E | Q8P3BZZRYG24E |
|---|---|---|---|---|
| Manufacturer | APEM Inc. | APEM Inc. | APEM Inc. | APEM Inc. |
| Product Status | Active | Active | Active | Active |
| Type | LED | LED | LED | LED |
| Lamp Color | Green, Red, Yellow | Green, Red, Yellow | Green, Red, Yellow | Green, Red, Yellow |
| Lens Color | - | - | - | - |
| Lens Transparency | Diffused | Diffused | Diffused | Diffused |
| Ratings | DC | DC | DC | DC |
| Voltage | 24V Green, 24V Red, 24V Yellow | 24V Green, 24V Red, 24V Yellow | 24V Green, 24V Red, 24V Yellow | 24V |
| Current | 20mA Green, 20mA Red, 20mA Yellow | 20mA Green, 20mA Red, 20mA Yellow | 20mA Green, 20mA Red, 20mA Yellow | 20mA |
| Panel Cutout Shape | Round | Round | Round | Round |
| Panel Cutout Dimensions | 0.31" (7.87mm) | 0.31" (7.87mm) | 0.31" (7.87mm) | 0.31" (7.87mm) |
| Lens Size | 5mm, T-1 3/4 | 5mm, T-1 3/4 | 5mm, T-1 3/4 | 5mm, T-1 3/4 |
| Lens Style | Round with Domed Top | Round with Domed Top | Round with Domed Top | Round with Domed Top |
| Millicandela Rating | 15mcd Green, 60mcd Red, 13mcd Yellow | 15mcd Green, 60mcd Red, 13mcd Yellow | 15mcd Green, 60mcd Red, 13mcd Yellow | 15mcd Green, 60mcd Red, 13mcd Yellow |
| Wavelength - Peak | - | - | - | - |
| Viewing Angle | 100° | 100° | 100° | 100° |
| Termination Style | Wire Leads - 7.87" (200.00mm) | Wire Leads - 7.87" (200.00mm) | Solder Lug | Wire Leads - 7.87" (200.00mm) |
| Ingress Protection | IP67 | IP67 | IP67 | IP67 |
| Features | - | - | - | - |
