Please send RFQ , we will respond immediately.
| Part Number | PM7528HPZ | PM7528HSZ | PM7524HPZ | PM7528FPZ | PM7528GPZ | PM7528HP | PM7528HPC |
|---|---|---|---|---|---|---|---|
| Manufacturer | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| Product Status | Active | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Active |
| Number of Bits | 8 | - | - | - | 8 | - | 8 |
| Number of D/A Converters | 2 | - | - | - | 2 | - | 2 |
| Settling Time | 200ns | - | - | - | 400ns | - | 200ns |
| Output Type | Current - Unbuffered | - | - | - | Current - Unbuffered | - | Current - Unbuffered |
| Differential Output | Yes | - | - | - | No | - | Yes |
| Data Interface | Parallel | - | - | - | Parallel | - | Parallel |
| Reference Type | External | - | - | - | External | - | External |
| Voltage - Supply, Analog | 5V ~ 15V | - | - | - | 5V ~ 15V | - | 5V ~ 15V |
| Voltage - Supply, Digital | 5V ~ 15V | - | - | - | 5V ~ 15V | - | 5V ~ 15V |
| INL/DNL (LSB) | ±0.5, ±1 | - | - | - | ±0.5 (Max), ±1 (Max) | - | ±0.5, ±1 |
| Architecture | Multiplying DAC, R-2R | - | - | - | R-2R | - | Multiplying DAC, R-2R |
| Operating Temperature | 0°C ~ 70°C | - | - | - | 0°C ~ 70°C | - | 0°C ~ 70°C |
| Package / Case | 20-DIP (0.300", 7.62mm) | 20-SOIC (0.295", 7.50mm Width) | 16-DIP (0.300", 7.62mm) | 20-DIP (0.300", 7.62mm) | 20-DIP (0.300", 7.62mm) | 20-DIP (0.300", 7.62mm) | 20-LCC (J-Lead) |
| Supplier Device Package | 20-DIP | 20-SOIC | 16-PDIP | 20-PDIP | 20-PDIP | 20-PDIP | 20-PLCC (9x9) |
| Mounting Type | Through Hole | Surface Mount | Through Hole | Through Hole | Through Hole | Through Hole | Surface Mount |
