Please send RFQ , we will respond immediately.
| Part Number | MAX6969AUG+ | MAX6979AUG+ | MAX6969AUG+T | MAX6969AWG+ | MAX6969ANG+ |
|---|---|---|---|---|---|
| Manufacturer | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated |
| Product Status | Active | Active | Active | Active | Active |
| Type | Linear | Linear | Linear | Linear | Linear |
| Topology | Shift Register | Shift Register | Shift Register | Shift Register | Shift Register |
| Internal Switch(s) | Yes | Yes | Yes | Yes | Yes |
| Number of Outputs | 16 | 16 | 16 | 16 | 16 |
| Voltage - Supply (Min) | 3V | 3V | 3V | 3V | 3V |
| Voltage - Supply (Max) | 5.5V | 5.5V | 5.5V | 5.5V | 5.5V |
| Voltage - Output | 5.5V | 5.5V | 5.5V | 5.5V | 5.5V |
| Current - Output / Channel | 55mA | 55mA | 55mA | 55mA | 55mA |
| Frequency | - | - | - | - | - |
| Dimming | - | - | - | - | - |
| Applications | Signage | Lighting, Signage | Signage | Signage | Signage |
| Operating Temperature | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Through Hole |
| Package / Case | 24-TSSOP (0.173", 4.40mm Width) | 24-TSSOP (0.173", 4.40mm Width) | 24-TSSOP (0.173", 4.40mm Width) | 24-SOIC (0.295", 7.50mm Width) | 24-DIP (0.300", 7.62mm) |
| Supplier Device Package | 24-TSSOP | 24-TSSOP | 24-TSSOP | 24-SOIC | 24-PDIP |
