| Part Number | MAX6796TPZD1+ | MAX6796TPZD2+ | MAX6796TPZD4+ | MAX6796TPZD3+ | MAX6796TPZD1+T | MAX6795TPZD1+ | MAX6796TPLD1+ | MAX6796TPMD1+ | MAX6796TPSD1+ | MAX6796TPTD1+ | MAX6796TPVD1+ | MAX6796TPWD1+ | MAX6796TPYD1+ | MAX6796TPZD0+ |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Manufacturer | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated |
| Product Status | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete |
| Type | Regulator/Supervisor | Regulator/Supervisor | Regulator/Supervisor | Regulator/Supervisor | Regulator/Supervisor | Regulator/Supervisor | Regulator/Supervisor | Regulator/Supervisor | Regulator/Supervisor | Regulator/Supervisor | Regulator/Supervisor | Regulator/Supervisor | Regulator/Supervisor | Regulator/Supervisor |
| Number of Voltages Monitored | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Voltage - Threshold | 2.313V, Adj | 2.313V, Adj | 2.313V, Adj | 2.313V, Adj | 2.313V, Adj | 2.313V, Adj | 4.625V, Adj | 4.375V, Adj | 2.888V, Adj | 3.053V, Adj | 1.575V, Adj | 1.665V, Adj | 2.188V, Adj | 2.313V, Adj |
| Output | Push-Pull, Totem Pole | Push-Pull, Totem Pole | Push-Pull, Totem Pole | Push-Pull, Totem Pole | Push-Pull, Totem Pole | Open Drain or Open Collector | Push-Pull, Totem Pole | Push-Pull, Totem Pole | Push-Pull, Totem Pole | Push-Pull, Totem Pole | Push-Pull, Totem Pole | Push-Pull, Totem Pole | Push-Pull, Totem Pole | Push-Pull, Totem Pole |
| Reset | Active Low | Active Low | Active Low | Active Low | Active Low | Active Low | Active Low | Active Low | Active Low | Active Low | Active Low | Active Low | Active Low | Active Low |
| Reset Timeout | 2.187ms Minimum | 8.75ms Minimum | 140ms Minimum | 35ms Minimum | 2.187ms Minimum | 2.187ms Minimum | 2.187ms Minimum | 2.187ms Minimum | 2.187ms Minimum | 2.187ms Minimum | 2.187ms Minimum | 2.187ms Minimum | 2.187ms Minimum | 35µs Typical |
| Operating Temperature | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 20-WQFN Exposed Pad | 20-WQFN Exposed Pad | 20-WQFN Exposed Pad | 20-WQFN Exposed Pad | 20-WQFN Exposed Pad | 20-WQFN Exposed Pad | 20-WQFN Exposed Pad | 20-WQFN Exposed Pad | 20-WQFN Exposed Pad | 20-WQFN Exposed Pad | 20-WQFN Exposed Pad | 20-WQFN Exposed Pad | 20-WQFN Exposed Pad | 20-WQFN Exposed Pad |
| Supplier Device Package | 20-TQFN (5x5) | 20-TQFN (5x5) | 20-TQFN (5x5) | 20-TQFN (5x5) | 20-TQFN (5x5) | 20-TQFN (5x5) | 20-TQFN (5x5) | 20-TQFN (5x5) | 20-TQFN (5x5) | 20-TQFN (5x5) | 20-TQFN (5x5) | 20-TQFN (5x5) | 20-TQFN (5x5) | 20-TQFN (5x5) |
