MAX504EPD
  • Share:

Analog Devices Inc./Maxim Integrated MAX504EPD

Manufacturer No:
MAX504EPD
Manufacturer:
Analog Devices Inc./Maxim Integrated
Package:
Tube
Datasheet:
MAX504EPD Datasheet
ECAD Model:
-
Description:
IC DAC 10BIT V-OUT 14DIP
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Number of Bits:10
Number of D/A Converters:1
Settling Time:25µs (Typ)
Output Type:Voltage - Buffered
Differential Output:No
Data Interface:SPI
Reference Type:External, Internal
Voltage - Supply, Analog:±5V
Voltage - Supply, Digital:5V
INL/DNL (LSB):±0.5 (Max), ±1 (Max)
Architecture:R-2R
Operating Temperature:-40°C ~ 85°C
Package / Case:14-DIP (0.300", 7.62mm)
Supplier Device Package:14-PDIP
Mounting Type:Through Hole
0 Remaining View Similar

In Stock

-
584

Please send RFQ , we will respond immediately.

Similar Products

Part Number MAX504EPD MAX504ESD   MAX504EPD+   MAX504CPD
Manufacturer Analog Devices Inc./Maxim Integrated Analog Devices Inc./Maxim Integrated Analog Devices Inc./Maxim Integrated Analog Devices Inc./Maxim Integrated
Product Status Obsolete Obsolete Last Time Buy Obsolete
Number of Bits 10 10 10 10
Number of D/A Converters 1 1 1 1
Settling Time 25µs (Typ) 25µs (Typ) 25µs (Typ) 25µs (Typ)
Output Type Voltage - Buffered Voltage - Buffered Voltage - Buffered Voltage - Buffered
Differential Output No No No No
Data Interface SPI SPI SPI SPI
Reference Type External, Internal External, Internal External, Internal External, Internal
Voltage - Supply, Analog ±5V ±5V ±5V ±5V
Voltage - Supply, Digital 5V 5V 5V 5V
INL/DNL (LSB) ±0.5 (Max), ±1 (Max) ±0.5 (Max), ±1 (Max) ±0.5 (Max), ±1 (Max) ±0.5 (Max), ±1 (Max)
Architecture R-2R R-2R R-2R R-2R
Operating Temperature -40°C ~ 85°C -40°C ~ 85°C -40°C ~ 85°C 0°C ~ 70°C
Package / Case 14-DIP (0.300", 7.62mm) 14-SOIC (0.154", 3.90mm Width) 14-DIP (0.300", 7.62mm) 14-DIP (0.300", 7.62mm)
Supplier Device Package 14-PDIP 14-SOIC 14-PDIP 14-PDIP
Mounting Type Through Hole Surface Mount Through Hole Through Hole
