| Part Number | MAX4754AEBE+ | MAX4754AEBE+T | MAX4754AETE+ |
|---|---|---|---|
| Manufacturer | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated |
| Product Status | Active | Obsolete | Obsolete |
| Switch Circuit | - | SPDT | - |
| Multiplexer/Demultiplexer Circuit | - | 2:1 | - |
| Number of Circuits | - | 4 | - |
| On-State Resistance (Max) | - | 850mOhm | - |
| Channel-to-Channel Matching (ΔRon) | - | 100mOhm | - |
| Voltage - Supply, Single (V+) | - | 1.8V ~ 5.5V | - |
| Voltage - Supply, Dual (V±) | - | - | - |
| Switch Time (Ton, Toff) (Max) | - | 140ns, 50ns | - |
| -3db Bandwidth | - | 10MHz | - |
| Charge Injection | - | 300pC | - |
| Channel Capacitance (CS(off), CD(off)) | - | 180pF, 300pF | - |
| Current - Leakage (IS(off)) (Max) | - | 4nA | - |
| Crosstalk | - | -90dB @ 100kHz | - |
| Operating Temperature | - | -40°C ~ 85°C (TA) | - |
| Mounting Type | - | Surface Mount | - |
| Package / Case | - | 16-WFBGA, CSPBGA | - |
| Supplier Device Package | - | 16-UCSP (2x2) | - |
