Analog Devices Inc. LTC7803JUD#TRPBF

Manufacturer No:
LTC7803JUD#TRPBF
Manufacturer:
Analog Devices Inc.
Package:
Tape & Reel (TR)
Datasheet:
LTC7803JUD#TRPBF Datasheet
ECAD Model:
-
Description:
LOW IQ SYNCHRONOUS BUCK CONTROLL
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Output Type:Transistor Driver
Function:Step-Down
Output Configuration:Positive
Topology:Buck
Number of Outputs:1
Output Phases:1
Voltage - Supply (Vcc/Vdd):4.5V ~ 40V
Frequency - Switching:100kHz ~ 3MHz
Duty Cycle (Max):100%
Synchronous Rectifier:Yes
Clock Sync:Yes
Serial Interfaces:-
Control Features:Enable, Frequency Control, Phase Control
Operating Temperature:-40°C ~ 150°C (TJ)
Mounting Type:Surface Mount
Package / Case:16-WFQFN Exposed Pad
Supplier Device Package:16-QFN (3x3)
