| Part Number | LTC6416CDDB#TRPBF | LTC6416IDDB#TRPBF | LTC6416CDDB#TRMPBF |
|---|---|---|---|
| Manufacturer | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| Product Status | Active | Active | Active |
| Amplifier Type | Buffer | Buffer | Buffer |
| Number of Circuits | 1 | 1 | 1 |
| Output Type | Differential | Differential | Differential |
| Slew Rate | 3400V/µs | 3400V/µs | 3400V/µs |
| Gain Bandwidth Product | - | - | - |
| -3db Bandwidth | 2 GHz | 2 GHz | 2 GHz |
| Current - Input Bias | 5 µA | 5 µA | 5 µA |
| Voltage - Input Offset | 500 µV | 500 µV | 500 µV |
| Current - Supply | 42mA | 42mA | 42mA |
| Current - Output / Channel | 20 mA | 20 mA | 20 mA |
| Voltage - Supply Span (Min) | 2.7 V | 2.7 V | 2.7 V |
| Voltage - Supply Span (Max) | 3.9 V | 3.9 V | 3.9 V |
| Operating Temperature | 0°C ~ 70°C | -40°C ~ 85°C | 0°C ~ 70°C |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 10-WFDFN Exposed Pad | 10-WFDFN Exposed Pad | 10-WFDFN Exposed Pad |
| Supplier Device Package | 10-DFN (3x2) | 10-DFN (3x2) | 10-DFN (3x2) |
