LTC3866IFE
  • Share:

Analog Devices Inc. LTC3866IFE

Manufacturer No:
LTC3866IFE
Manufacturer:
Analog Devices Inc.
Package:
Tube
Datasheet:
LTC3866IFE Datasheet
ECAD Model:
-
Description:
IC POWER MANAGEMENT
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Output Type:Transistor Driver
Function:Step-Down
Output Configuration:Positive
Topology:Buck
Number of Outputs:1
Output Phases:1
Voltage - Supply (Vcc/Vdd):4.5V ~ 38V
Frequency - Switching:250kHz ~ 770kHz
Duty Cycle (Max):-
Synchronous Rectifier:Yes
Clock Sync:No
Serial Interfaces:-
Control Features:Current Limit, Enable, Frequency Control, Power Good, Soft Start, Tracking
Operating Temperature:-40°C ~ 125°C (TJ)
Mounting Type:Surface Mount
Package / Case:24-TSSOP (0.173", 4.40mm Width) Exposed Pad
Supplier Device Package:24-TSSOP
0 Remaining View Similar

In Stock

-
294

Please send RFQ , we will respond immediately.

Similar Products

Part Number LTC3866IFE LTC3862IFE   LTC3865IFE   LTC3866EFE
Manufacturer Analog Devices Inc. Analog Devices Inc. Analog Devices Inc. Analog Devices Inc.
Product Status Obsolete Obsolete Obsolete Obsolete
Output Type Transistor Driver Transistor Driver Transistor Driver Transistor Driver
Function Step-Down Step-Up, Step-Up/Step-Down Step-Down Step-Down
Output Configuration Positive Positive Positive Positive
Topology Buck Boost, SEPIC Buck Buck
Number of Outputs 1 2 2 1
Output Phases 1 2 2 1
Voltage - Supply (Vcc/Vdd) 4.5V ~ 38V 4V ~ 36V 4.5V ~ 38V 4.5V ~ 38V
Frequency - Switching 250kHz ~ 770kHz 75kHz ~ 500kHz 250kHz ~ 770kHz 250kHz ~ 770kHz
Duty Cycle (Max) - 96% 95% -
Synchronous Rectifier Yes No Yes Yes
Clock Sync No Yes No No
Serial Interfaces - - - -
Control Features Current Limit, Enable, Frequency Control, Power Good, Soft Start, Tracking Enable, Frequency Control, Phase Control, Soft Start Current Limit, Enable, Frequency Control, Power Good, Soft Start, Tracking Current Limit, Enable, Frequency Control, Power Good, Soft Start, Tracking
Operating Temperature -40°C ~ 125°C (TJ) -40°C ~ 125°C (TJ) -40°C ~ 125°C (TJ) -40°C ~ 125°C (TJ)
Mounting Type Surface Mount Surface Mount Surface Mount Surface Mount
Package / Case 24-TSSOP (0.173", 4.40mm Width) Exposed Pad 24-TSSOP (0.173", 4.40mm Width) Exposed Pad 38-TFSOP (0.173", 4.40mm Width) Exposed Pad 24-TSSOP (0.173", 4.40mm Width) Exposed Pad
Supplier Device Package 24-TSSOP 24-TSSOP 38-TSSOP-EP 24-TSSOP
