LTC1922EG-1#PBF
  • Share:

Analog Devices Inc. LTC1922EG-1#PBF

Manufacturer No:
LTC1922EG-1#PBF
Manufacturer:
Analog Devices Inc.
Package:
Tube
Datasheet:
LTC1922EG-1#PBF Datasheet
ECAD Model:
-
Description:
IC REG CTRLR FULL-BRIDGE 20SSOP
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Output Type:Transistor Driver
Function:Step-Up/Step-Down
Output Configuration:Positive, Isolation Capable
Topology:Full-Bridge
Number of Outputs:1
Output Phases:1
Voltage - Supply (Vcc/Vdd):3.8V ~ 10.3V
Frequency - Switching:Up to 1MHz
Duty Cycle (Max):99%
Synchronous Rectifier:Yes
Clock Sync:Yes
Serial Interfaces:-
Control Features:Ramp, Soft Start
Operating Temperature:-40°C ~ 85°C (TA)
Mounting Type:Surface Mount
Package / Case:20-SSOP (0.209", 5.30mm Width)
Supplier Device Package:20-SSOP
0 Remaining View Similar

In Stock

$13.48
37

Please send RFQ , we will respond immediately.

Similar Products

Part Number LTC1922EG-1#PBF LTC1922EN-1#PBF   LTC1922IG-1#PBF
Manufacturer Analog Devices Inc. Analog Devices Inc. Analog Devices Inc.
Product Status Active Active Active
Output Type Transistor Driver Transistor Driver Transistor Driver
Function Step-Up/Step-Down Step-Up/Step-Down Step-Up/Step-Down
Output Configuration Positive, Isolation Capable Positive, Isolation Capable Positive, Isolation Capable
Topology Full-Bridge Full-Bridge Full-Bridge
Number of Outputs 1 1 1
Output Phases 1 1 1
Voltage - Supply (Vcc/Vdd) 3.8V ~ 10.3V 3.8V ~ 10.3V 3.8V ~ 10.3V
Frequency - Switching Up to 1MHz Up to 1MHz Up to 1MHz
Duty Cycle (Max) 99% 99% 99%
Synchronous Rectifier Yes Yes Yes
Clock Sync Yes Yes Yes
Serial Interfaces - - -
Control Features Ramp, Soft Start Ramp, Soft Start Ramp, Soft Start
Operating Temperature -40°C ~ 85°C (TA) -40°C ~ 85°C (TA) -40°C ~ 85°C (TA)
Mounting Type Surface Mount Through Hole Surface Mount
Package / Case 20-SSOP (0.209", 5.30mm Width) 20-DIP (0.300", 7.62mm) 20-SSOP (0.209", 5.30mm Width)
Supplier Device Package 20-SSOP 20-PDIP 20-SSOP
