| Part Number | LT8648SJV#PBF | LT8648SJV#WPBF | LT8638SJV#PBF | LT8648SEV#PBF | LT8648SHV#PBF |
|---|---|---|---|---|---|
| Manufacturer | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| Product Status | Active | Active | Active | Active | Active |
| Function | Step-Down | Step-Down | Step-Down | Step-Down | Step-Down |
| Output Configuration | Positive | Positive | Positive | Positive | Positive |
| Topology | Buck | Buck | Buck | Buck | Buck |
| Output Type | Adjustable | Adjustable | Adjustable | Adjustable | Adjustable |
| Number of Outputs | 1 | 1 | 1 | 1 | 1 |
| Voltage - Input (Min) | 3V | 3V | 2.8V | 3V | 3V |
| Voltage - Input (Max) | 42V | 42V | 42V | 42V | 42V |
| Voltage - Output (Min/Fixed) | 0.6V | 0.6V | 0.6V | 0.6V | 0.6V |
| Voltage - Output (Max) | 42V | 42V | 42V | 42V | 42V |
| Current - Output | 15A | 15A | 12A | 15A | 15A |
| Frequency - Switching | 200kHz ~ 2.2MHz | 200kHz ~ 2.2MHz | 200kHz ~ 3MHz | 200kHz ~ 2.2MHz | 200kHz ~ 2.2MHz |
| Synchronous Rectifier | Yes | Yes | Yes | Yes | Yes |
| Operating Temperature | -40°C ~ 150°C (TJ) | -40°C ~ 150°C (TJ) | -40°C ~ 150°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 36-TFQFN Exposed Pad | 36-TFQFN Exposed Pad | 28-TFQFN Exposed Pad | 36-TFQFN Exposed Pad | 36-TFQFN Exposed Pad |
| Supplier Device Package | 36-LQFN (7x4) | 36-LQFN (7x4) | 28-LQFN (5x4) | 36-LQFN (7x4) | 36-LQFN (7x4) |
