LT8390HUFD#PBF
  • Share:

Analog Devices Inc. LT8390HUFD#PBF

Manufacturer No:
LT8390HUFD#PBF
Manufacturer:
Analog Devices Inc.
Package:
Tube
Datasheet:
LT8390HUFD#PBF Datasheet
ECAD Model:
-
Description:
60V SYNCHRONOUS 4-SWITCH BUCK-BO
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Output Type:Transistor Driver
Function:Step-Up/Step-Down
Output Configuration:Positive
Topology:Buck-Boost
Number of Outputs:1
Output Phases:1
Voltage - Supply (Vcc/Vdd):4V ~ 60V
Frequency - Switching:190kHz ~ 630kHz
Duty Cycle (Max):95%
Synchronous Rectifier:Yes
Clock Sync:Yes
Serial Interfaces:-
Control Features:Current Limit, Frequency Control, Soft Start
Operating Temperature:-40°C ~ 150°C (TJ)
Mounting Type:Surface Mount
Package / Case:28-WFQFN Exposed Pad
Supplier Device Package:28-QFN (4x5)
0 Remaining View Similar

In Stock

$12.53
6

Please send RFQ , we will respond immediately.

Similar Products

Part Number LT8390HUFD#PBF LT8390IUFD#PBF   LT8390JUFD#PBF   LT8392HUFD#PBF   LT8390AHUFD#PBF   LT8390EUFD#PBF
Manufacturer Analog Devices Inc. Analog Devices Inc. Analog Devices Inc. Analog Devices Inc. Analog Devices Inc. Analog Devices Inc.
Product Status Active Active Active Active Active Active
Output Type Transistor Driver Transistor Driver Transistor Driver Transistor Driver Transistor Driver Transistor Driver
Function Step-Up/Step-Down Step-Up/Step-Down Step-Up/Step-Down Step-Up/Step-Down Step-Up/Step-Down Step-Up/Step-Down
Output Configuration Positive Positive Positive Positive Positive Positive
Topology Buck-Boost Buck-Boost Buck-Boost Buck-Boost Buck-Boost Buck-Boost
Number of Outputs 1 1 1 1 1 1
Output Phases 1 1 1 2 1 1
Voltage - Supply (Vcc/Vdd) 4V ~ 60V 4V ~ 60V 4V ~ 60V 3V ~ 60V 4V ~ 60V 4V ~ 60V
Frequency - Switching 190kHz ~ 630kHz 190kHz ~ 630kHz 150kHz ~ 650kHz 400kHz 645kHz ~ 2.1MHz 190kHz ~ 630kHz
Duty Cycle (Max) 95% 95% 95% - 95% 95%
Synchronous Rectifier Yes Yes Yes Yes Yes Yes
Clock Sync Yes Yes Yes Yes Yes Yes
Serial Interfaces - - - - - -
Control Features Current Limit, Frequency Control, Soft Start Current Limit, Frequency Control, Soft Start Current Limit, Enable, Frequency Control, Phase Control, Power Good, Soft Start Enable, Frequency Control, Power Good, Soft Start Current Limit, Frequency Control, Soft Start Current Limit, Frequency Control, Soft Start
Operating Temperature -40°C ~ 150°C (TJ) -40°C ~ 125°C (TJ) -40°C ~ 150°C (TJ) -40°C ~ 150°C (TJ) -40°C ~ 150°C (TJ) -40°C ~ 125°C (TJ)
Mounting Type Surface Mount Surface Mount Surface Mount Surface Mount Surface Mount Surface Mount
Package / Case 28-WFQFN Exposed Pad 28-WFQFN Exposed Pad 28-WFQFN Exposed Pad 28-WFQFN Exposed Pad 28-WFQFN Exposed Pad 28-WFQFN Exposed Pad
Supplier Device Package 28-QFN (4x5) 28-QFN (4x5) 28-QFN (4x5) 28-QFN (4x5) 28-QFN (4x5) 28-QFN (4x5)
