| Part Number | ADM694SQ | ADM696SQ | ADM695SQ | ADM697SQ | ADM698SQ | ADM699SQ | ADM690SQ | ADM691SQ | ADM692SQ | ADM693SQ |
|---|---|---|---|---|---|---|---|---|---|---|
| Manufacturer | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| Product Status | Obsolete | Active | Obsolete | Obsolete | Obsolete | Obsolete | Active | Active | Active | Active |
| Type | Battery Backup Circuit | Battery Backup Circuit | Battery Backup Circuit | Battery Backup Circuit | Simple Reset/Power-On Reset | Simple Reset/Power-On Reset | Battery Backup Circuit | Battery Backup Circuit | Battery Backup Circuit | Simple Reset/Power-On Reset |
| Number of Voltages Monitored | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Voltage - Threshold | 4.65V | 1.3V | 4.65V | 1.3V | 4.65V | 4.65V | 4.65V | 4.65V | 4.4V | 4.4V |
| Output | Push-Pull, Totem Pole | Push-Pull, Push-Pull | Open Drain, Push-Pull | Push-Pull, Push-Pull | Push-Pull, Push-Pull | Push-Pull, Push-Pull | Push-Pull, Totem Pole | Open Drain, Push-Pull | Push-Pull, Totem Pole | Push-Pull, Totem Pole |
| Reset | Active Low | Active High/Active Low | Active High/Active Low | Active High/Active Low | Active High/Active Low | Active High/Active Low | Active Low | Active High/Active Low | Active Low | Active High/Active Low |
| Reset Timeout | 140ms Minimum | 35ms Minimum | 140ms Minimum | 35ms Minimum | 140ms Minimum | 140ms Minimum | 35ms Minimum | 35ms Minimum | 35ms Minimum | 35ms Minimum |
| Operating Temperature | -55°C ~ 125°C (TA) | -55°C ~ 125°C (TA) | -55°C ~ 125°C (TA) | -55°C ~ 125°C | -55°C ~ 125°C (TA) | -55°C ~ 125°C (TA) | -55°C ~ 125°C (TA) | -55°C ~ 125°C (TA) | -55°C ~ 125°C (TA) | -55°C ~ 125°C |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | 8-CDIP (0.300", 7.62mm) | 16-CDIP (0.300", 7.62mm) | 16-CDIP (0.300", 7.62mm) | 16-CDIP (0.300", 7.62mm) | 8-CDIP (0.300", 7.62mm) | 8-CDIP (0.300", 7.62mm) | 8-CDIP (0.300", 7.62mm) | 16-CDIP (0.300", 7.62mm) | 8-CDIP (0.300", 7.62mm) | 16-CDIP (0.300", 7.62mm) |
| Supplier Device Package | 8-CERDIP | 16-CERDIP | 16-CERDIP | 16-CERDIP | 8-CERDIP | 8-CERDIP | 8-CERDIP | 16-CERDIP | 8-CERDIP | 16-CERDIP |
