| Part Number | ADCMP581BCPZ-WP | ADCMP582BCPZ-WP | ADCMP580BCPZ-WP | ADCMP581BCP-WP |
|---|---|---|---|---|
| Manufacturer | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| Product Status | Active | Active | Active | Obsolete |
| Type | with Latch | with Latch | with Latch | - |
| Number of Elements | 1 | 1 | 1 | - |
| Output Type | Complementary, ECL | Complementary, PECL | CML, Complementary | - |
| Voltage - Supply, Single/Dual (±) | ±4.5V ~ 5.5V | ±4.5V ~ 5.5V | ±4.5V ~ 5.5V | - |
| Voltage - Input Offset (Max) | 10mV @ ±5V | 10mV @ ±5V | 10mV @ ±5V | - |
| Current - Input Bias (Max) | 30µA @ ±5V | 30µA @ ±5V | 30µA @ ±5V | - |
| Current - Output (Typ) | 44mA @ 5V | 44mA @ 5V | 44mA @ 5V | - |
| Current - Quiescent (Max) | 8mA | 8mA | 8mA | - |
| CMRR, PSRR (Typ) | 60dB CMRR, 75dB PSRR | 60dB CMRR, 75dB PSRR | 60dB CMRR, 75dB PSRR | - |
| Propagation Delay (Max) | 0.18ns | 0.18ns | 0.18ns | - |
| Hysteresis | 1mV | 1mV | 1mV | - |
| Operating Temperature | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C | - |
| Package / Case | 16-WFQFN Exposed Pad, CSP | 16-WFQFN Exposed Pad, CSP | 16-WFQFN Exposed Pad, CSP | - |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | - |
| Supplier Device Package | 16-LFCSP (3x3) | 16-LFCSP (3x3) | 16-LFCSP (3x3) | - |
