| Part Number | AD8617ACPZ-R7 | AD8617ACPZ-RL | AD8617ACPZ-R2 |
|---|---|---|---|
| Manufacturer | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| Product Status | Active | Obsolete | Discontinued at Digi-Key |
| Amplifier Type | CMOS | CMOS | CMOS |
| Number of Circuits | 2 | 2 | 2 |
| Output Type | Rail-to-Rail | Rail-to-Rail | Rail-to-Rail |
| Slew Rate | 0.1V/µs | 0.1V/µs | 0.1V/µs |
| Gain Bandwidth Product | 400 kHz | 400 kHz | 400 kHz |
| -3db Bandwidth | - | - | - |
| Current - Input Bias | 0.2 pA | 0.2 pA | 0.2 pA |
| Voltage - Input Offset | 400 µV | 400 µV | 400 µV |
| Current - Supply | 38µA | 38µA | 38µA |
| Current - Output / Channel | 80 mA | 80 mA | 80 mA |
| Voltage - Supply Span (Min) | 1.8 V | 1.8 V | 1.8 V |
| Voltage - Supply Span (Max) | 5 V | 5 V | 5 V |
| Operating Temperature | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 8-WFDFN Exposed Pad, CSP | 8-WFDFN Exposed Pad, CSP | 8-WFDFN Exposed Pad, CSP |
| Supplier Device Package | 8-LFCSP-WD (3x3) | 8-LFCSP-WD (3x3) | 8-LFCSP-WD (3x3) |
