| Part Number | AD8561AN | AD8561ANZ | AD8561AR | AD8564AN |
|---|---|---|---|---|
| Manufacturer | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| Product Status | Obsolete | Active | Obsolete | Obsolete |
| Type | General Purpose | General Purpose | General Purpose | General Purpose |
| Number of Elements | 1 | 1 | 1 | 4 |
| Output Type | CMOS, Complementary, TTL | CMOS, Complementary, TTL | CMOS, Complementary, TTL | CMOS, TTL |
| Voltage - Supply, Single/Dual (±) | 3V ~ 10V, ±1.5V ~ 5V | 3V ~ 10V, ±1.5V ~ 5V | 3V ~ 10V, ±1.5V ~ 5V | - |
| Voltage - Input Offset (Max) | 7mV @ 5V | 7mV @ 5V | 7mV @ 5V | 7mV @ 5V |
| Current - Input Bias (Max) | 6µA @ 5V | 6µA @ 5V | 6µA @ 5V | 4µA @ 5V |
| Current - Output (Typ) | - | - | - | - |
| Current - Quiescent (Max) | 6mA, 3.3mA, 5.5mA | 6mA, 3.3mA, 5.5mA | 6mA, 3.3mA, 5.5mA | 14mA, 14mA, 7mA |
| CMRR, PSRR (Typ) | 85dB CMRR, 65dB PSRR | 85dB CMRR, 65dB PSRR | 85dB CMRR, 65dB PSRR | 85dB CMRR, 80dB PSRR |
| Propagation Delay (Max) | 9.8ns | 9.8ns | 9.8ns | 9.8ns |
| Hysteresis | - | - | - | - |
| Operating Temperature | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C |
| Package / Case | 8-DIP (0.300", 7.62mm) | 8-DIP (0.300", 7.62mm) | 8-SOIC (0.154", 3.90mm Width) | 16-DIP (0.300", 7.62mm) |
| Mounting Type | Through Hole | Through Hole | Surface Mount | Through Hole |
| Supplier Device Package | 8-PDIP | 8-PDIP | 8-SOIC | 16-PDIP |
