Please send RFQ , we will respond immediately.
| Part Number | AD707BH | AD707SH | AD707TH | AD707AH |
|---|---|---|---|---|
| Manufacturer | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| Product Status | Active | Active | Active | Active |
| Amplifier Type | General Purpose | General Purpose | General Purpose | General Purpose |
| Number of Circuits | 1 | 1 | 1 | 1 |
| Output Type | - | - | - | - |
| Slew Rate | 0.3V/µs | 0.3V/µs | 0.3V/µs | 0.3V/µs |
| Gain Bandwidth Product | 900 kHz | 900 kHz | 900 kHz | 900 kHz |
| -3db Bandwidth | - | - | - | - |
| Current - Input Bias | - | 1.5 nA | 1.5 nA | 2 nA |
| Voltage - Input Offset | - | 10 µV | 10 µV | 30 µV |
| Current - Supply | - | 2.5mA | 2.5mA | 2.5mA |
| Current - Output / Channel | 10 mA | 10 mA | 10 mA | 10 mA |
| Voltage - Supply Span (Min) | 22 V | 22 V | 22 V | 22 V |
| Voltage - Supply Span (Max) | 22 V | 22 V | 22 V | 22 V |
| Operating Temperature | -40°C ~ 85°C | -55°C ~ 125°C | -55°C ~ 125°C | -40°C ~ 85°C |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | TO-99-8 Metal Can | TO-99-8 Metal Can | TO-99-8 Metal Can | TO-99-8 Metal Can |
| Supplier Device Package | TO-99-8 | TO-99-8 | TO-99-8 | TO-99-8 |
