| Part Number | AD585SQ | AD585AQ | AD585SE |
|---|---|---|---|
| Manufacturer | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| Product Status | Active | Active | Active |
| Amplifier Type | Sample and Hold | Sample and Hold | Sample and Hold |
| Number of Circuits | 1 | 1 | 1 |
| Output Type | - | - | - |
| Slew Rate | 10V/µs | 10V/µs | 10V/µs |
| Gain Bandwidth Product | - | - | - |
| -3db Bandwidth | 2 MHz | 2 MHz | 2 MHz |
| Current - Input Bias | 2 nA | 2 nA | 2 nA |
| Voltage - Input Offset | 2 mV | 2 mV | 2 mV |
| Current - Supply | 10mA | 10mA | 10mA |
| Current - Output / Channel | 50 mA | 50 mA | 50 mA |
| Voltage - Supply Span (Min) | 10 V | 10 V | 10 V |
| Voltage - Supply Span (Max) | 36 V | 36 V | 36 V |
| Operating Temperature | -55°C ~ 125°C | -25°C ~ 85°C | -55°C ~ 125°C |
| Mounting Type | Through Hole | Through Hole | Surface Mount |
| Package / Case | 14-CDIP (0.300", 7.62mm) | 14-CDIP (0.300", 7.62mm) | 20-CLCC |
| Supplier Device Package | 14-CERDIP | 14-CERDIP | 20-CLCC (8.89x8.89) |
