| Part Number | AD521LD | AD521SD | AD521LDZ | AD521JD | AD521KD |
|---|---|---|---|---|---|
| Manufacturer | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| Product Status | Obsolete | Obsolete | Active | Obsolete | Obsolete |
| Amplifier Type | Instrumentation | Instrumentation | Instrumentation | Instrumentation | Instrumentation |
| Number of Circuits | 1 | 1 | 1 | 1 | 1 |
| Output Type | - | - | - | - | - |
| Slew Rate | 10V/µs | 10V/µs | 10V/µs | 10V/µs | 10V/µs |
| Gain Bandwidth Product | - | - | - | - | - |
| -3db Bandwidth | 2 MHz | 2 MHz | 2 MHz | 2 MHz | 2 MHz |
| Current - Input Bias | 40 nA | 40 nA | 40 nA | 80 nA | 40 nA |
| Voltage - Input Offset | 1 mV | 1.5 mV | 1 mV | 3 mV | 1.5 mV |
| Current - Supply | 5mA | 5mA | 5mA | 5mA | 5mA |
| Current - Output / Channel | - | - | - | - | - |
| Voltage - Supply Span (Min) | 10 V | 10 V | 10 V | 10 V | 10 V |
| Voltage - Supply Span (Max) | 36 V | 36 V | 36 V | 36 V | 36 V |
| Operating Temperature | 0°C ~ 70°C | -55°C ~ 125°C | 0°C ~ 70°C | 0°C ~ 70°C | 0°C ~ 70°C |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | 14-CDIP (0.300", 7.62mm) | 14-CDIP (0.300", 7.62mm) | 14-CDIP (0.300", 7.62mm) | 14-CDIP (0.300", 7.62mm) | 14-CDIP (0.300", 7.62mm) |
| Supplier Device Package | 14-CDIP | 14-CDIP | 14-CDIP | 14-CDIP | 14-CDIP |
