| Part Number | 5962-9098001M2A | 5962-9098001MPA | 5962-9098001MXA |
|---|---|---|---|
| Manufacturer | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| Product Status | Active | Active | Active |
| Amplifier Type | General Purpose | General Purpose | General Purpose |
| Number of Circuits | 1 | 1 | 1 |
| Output Type | - | - | - |
| Slew Rate | 250V/µs | 250V/µs | 250V/µs |
| Gain Bandwidth Product | 34 MHz | 34 MHz | 34 MHz |
| -3db Bandwidth | - | - | - |
| Current - Input Bias | 50 pA | 50 pA | 50 pA |
| Voltage - Input Offset | 1 mV | 1 mV | 1 mV |
| Current - Supply | 12mA | 12mA | 12mA |
| Current - Output / Channel | - | - | - |
| Voltage - Supply Span (Min) | 8 V | 8 V | 8 V |
| Voltage - Supply Span (Max) | 36 V | 36 V | 36 V |
| Operating Temperature | - | - | - |
| Mounting Type | Surface Mount | Through Hole | Surface Mount |
| Package / Case | 20-CLCC | 28-CDIP (0.600", 15.24mm) | 20-CLCC |
| Supplier Device Package | 20-CLCC (9x9) | 28-CDIP | 20-CLCC (9x9) |
