| Part Number | 5962-8770201RA | 5962-8770203RA | 5962-8780201RA | 5962-8770201RX | 5962-8770101RA |
|---|---|---|---|---|---|
| Manufacturer | Analog Devices Inc. | Analog Devices Inc./Maxim Integrated | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| Product Status | Active | Active | Active | Active | Active |
| Number of Bits | 12 | - | 8 | 12 | 8 |
| Number of D/A Converters | 1 | - | 4 | 1 | 2 |
| Settling Time | 2µs | - | 4µs | 2µs | 400ns |
| Output Type | Current - Unbuffered | - | Voltage - Buffered | Current - Unbuffered | Current - Unbuffered |
| Differential Output | No | - | No | No | No |
| Data Interface | Parallel | - | Parallel | Parallel | Parallel |
| Reference Type | External | - | External | External | External |
| Voltage - Supply, Analog | 5V ~ 15V | - | 11.4V ~ 16.5V, -5V | 5V ~ 15V | 5V ~ 15V |
| Voltage - Supply, Digital | 5V ~ 15V | - | 11.4V ~ 16.5V, -5V | 5V ~ 15V | 5V ~ 15V |
| INL/DNL (LSB) | ±2 (Max), ±4 (Max) | - | ±0.5 (Max), ±1 (Max) | ±2 (Max), ±4 (Max) | ±1 (Max), ±1 (Max) |
| Architecture | Multiplying DAC, R-2R | - | R-2R | R-2R | R-2R |
| Operating Temperature | -55°C ~ 125°C | - | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C |
| Package / Case | 20-CDIP (0.300", 7.62mm) | - | 20-CDIP (0.300", 7.62mm) | 20-CDIP (0.300", 7.62mm) | 20-CDIP (0.300", 7.62mm) |
| Supplier Device Package | 20-CERDIP | - | 20-CERDIP | 20-CERDIP | 20-CERDIP |
| Mounting Type | Through Hole | - | Through Hole | Through Hole | Through Hole |
